High Gain ATC Antenna
High Gain ATC Antenna List
| # | Model | Product Description | Frequency | Bandwidth | Gain | Download | ENQ | |
|---|---|---|---|---|---|---|---|---|
| 1 | SD-127 | VHF Air Band Stacked Dipole Antenna | 118- 37MHz | 118-137MHz | 3 dBd. |  |
 |
 |
| 2 | LP-118-400 | VHF UHF Air Band Log Periodic Antenna | 118-400MHz | 118-400MHz | 11 dBi. | |
|
|
| 3 | SD-312 | UHF Aviation Band Stacked Dipole Array | 225-400MHz | 60 MHz. | 3 dBd. | |
|
|
| 4 | CD-100-156 | VHF Aviation Band Omni Antenna | 100-156MHz | 100-156MHz | 2 dBi | |
|
|
| 5 | AC-100-400 | VHF UHF Aviation Band Omni Antenna | 100-400MHz | 100-400MHz | 2.14 dBi | |
|
|
| 6 | LP-108-470 | VHF UHF Air Band Log Periodic Antenna | 108-470MHz | 108-470MHz | 11 dBi. | |
|
|
| 7 | CD-108-175 | VHF Aviation Band Coaxial Dipole | 108-175MHz | 108-175MHz | 2.15 dBi | |
|
|
| 8 | AC-108-512 | VHF UHF Aviation Band Omni Antenna | 108-512MHz | 108-512MHz | 2 dBi. | |
|
|
| 9 | AC-112-156 | VHF Aviation Band Fiberglass Collinear | 112-156MHz | 112-156MHz | 2.14 dBi | |
|
|
| 10 | AY-128-16 | VHF Air Band 8 Stacked Yagi Array | 117-137MHz | 6 MHz. | 16 dBi. | |
|
|
| 11 | AQY-128 | VHF Aviation Band Quad Yagi Antenna | 117-137MHz | 6 MHz | 17.5 dBi | |
|
|
| 12 | AY-128 | VHF Aviation Band Yagi Antenna | 117-137MHz | 117-137MHz | 11 dBi | |
|
|
| 13 | AC6-127 | VHF Air Band Fiberglass Collinear | 117-137MHz | 10 MHz | 6 dBi | |
|
|
| 14 | AC-118-137 | VHF Air Band Fiberglass Omni Antenna | 118-137 MHz | 118-137Mhz | 2.15dBi | |
|
|
| 15 | AC5-127 | VHF High Gain ATC Antenna | 118-137MHz | 118-137MHz | 5 dBi | |
|
|
| 16 | SD9-128 | VHF Stacked Dipole ATC Antenna | 118-137MHz | 118-137MHz | 9 dBd | |
|
|
| 17 | ACHP-118-400 | VHF UHF High Power ATC Antenna | 118-400MHz | 118-400MHz | 2 dBi | |
|
|
| 18 | HL-225-400 | High Gain Circular Polarized Helical | 225-400MHz | 340-380MHz | 11 dBic | |
|
|
| 19 | LPDS-225-400 | UHF Dual Stacked 14dBi Log Periodic | 225-400MHz | 225-400MHz | 14 dBi | |
|
|
| 20 | AY-312-16 | UHF High Gain 8 Stacked Yagi Antenna | 225-400MHz | 20 MHz | 16 dBi | |
|
|
| 21 | AC5-312 | UHF High Gain Fiberglass Collinear | 225-400MHz | 225-400MHz | 5.15dBi | |
|
|
| 22 | LP-225-400 | UHF Air Band Log Periodic Antenna | 225-400MHz | 225-400MHz | 11 dBi | |
|
|
| 23 | AC3-127 | VHF Naval Shipboard Omni Antenna | 118-137MHz | 118-137MHz | 3 dBi | |
|
|
| 24 | AC-118-400 | VHF UHF Naval Shipboard Omni Antenna | 118-400MHz | 118-400MHz | 2 dBi | |
|
|
| 25 | AC3-312 | Naval Shipboard Broadband Omni | 225-400MHz | 225-400MHz | 3 dBi | |
|
|
| 26 | WD-100-500 | WD-100-500 wide band heavy duty fully | 100-500 MHz | 100-500MHz | 2.15 dBi | |
|
|
| 27 | WD-118-400 | WD-118-400 VHF UHF aviation band | 118-400 MHz | 118-400MHz | 2.15 dBi | |
|
|
| 28 | AWD-30-88 | Military Discone Antenna wide band disco... | 30 - 88 MHz. | Entire Band | 2.15 dBi | |
|
|
| 29 | AWD-118-400 | VHF UHF aviation band discone antenna | 118 - 400 MHz. | 118-400 MHz | 2 dBi. | |
|
|
High Gain ATC Antenna
ATC antennas are a specialized type of antenna used by air traffic control systems. They are used to communicate with aircraft in the air and to relay air traffic control instructions to pilots. It also helps in providing information about their location and status. ATC antennas are typically large, high-gain antennas that can transmit and receive signals over long distances.
ATC antennas must be able to operate in a wide range of conditions, including dense urban areas and mountainous terrain. They must also be able to withstand the high winds and weather conditions encountered in aviation. High gain ATC antennas must also be able to operate in close proximity to other antennas and electronic equipment without causing interference.
High Gain ATC Antenna Product List
High Gain ATC Antenna
Antenna Experts is a top leading manufacturer and supplier of MIL-STD VHF UHF ATC antennas in India. We offers wide range of ATC antenna solutions to meet any sort of industry need. Our high gain VHF UHF ATC antenna systems from the AY and AQY series are excellent choices for base station antennas at ATC locations. While covering a large Flight Information Region (FIR) such as a long or narrow strip with a wider elevation beam-width, or an Oceanic Information Region (OIC), such as a bay or gulf then high gain ATC antenna is required. In addition to this, we have the know-how to build and provide the systems with a variety of configurations to manage the beam-width in the required plane.
Antenna Experts manufacturer VHF and UHF ATC (air traffic control) antenna with different gain for directional and omni-directional features for military UHF ATC air band 225-400 MHz and civil aviation VHF UHF ATC band 117.975-137 MHz. Antenna Experts also creates extended range VHF UHF air traffic control (ATC) antenna that allow customers to precisely regulate the vertical and horizontal beam-width in the required plane. We are skilled in designing and supplying VHF UHF ATC antenna systems with a variety of configurations to regulate the beam-width in desired plane. In addition to the list that is shown in the "Aviation Band Antenna" area of our website.
The WD series aeronautical band discone antennas are robust, completely welded discone antennas that are especially designed to withstand the most extreme environments, where conventional antennas often fail. Ground, high gain marine antenna, and ground to air antenna may all benefit from the clear communication provided by VHF UHF ATC discone antennas' broad vertical beam-width. The completely welded aviation band discone antenna is ideal for oceanic applications, particularly in the arctic area where ice loading and vibration are major concerns.
Types of ATC Antenna
There are three types of ATC antennas: omni-directional, sector, and tracking.
- Omni-directional antennas are used to provide coverage in all directions. They are typically used at airports where the distance between the runway and the terminal is short.
- Sector antennas are used to provide directional coverage in a specific direction. They are used at airports where the distance between the runway and the terminal is long.
- Tracking antennas are used to provide directional coverage in two directions. They are used at airports where the distance between the runway and the terminal is very long.
Benefits of High Gain ATC Antenna
There are many benefits of using an ATC antenna. Some of these benefits include:
1. Increased range and performance
High gain ATC antenna can help to increase the range and performance of your system. This is because the antenna is designed to specifically target and receive signals from towers.
2. Improved reception
An ATC antenna can help to improve the reception of your system. This is because the antenna is designed to specifically target and receive signals from towers.
3. Enhanced reliability
An ATC antenna can help to enhance the reliability of your system. This is because the antenna is designed to specifically target and receive signals from towers.
4. Easy installation
An ATC antenna is typically very easy to install. This is because it typically comes with a mounting bracket that can be easily attached to a roof or mast.
5. Superior quality
High gain ATC antenna is typically made with superior quality materials. This helps to ensure that the antenna will last long for many years.
